Communication Cable SFTP Cat7 LAN Cable

Basic Info

Model NO.	SFTP CAT7
Shield	Pet/Al Foil
Drain	Tc
Jacket	PVC/PE/LSZH
UV, Jelly, Fr	Available
Color	Multiple-Choice
Transport Package	305m/Wooden Reel/CTN
Specification	ETL, CE, ROHS, ISO9001
Trademark	RISUN or OEM
Origin	Hangzhou, China(Mainland)
HS Code	8544491100
Production Capacity	20000 Boxes / Month

Product Description

Communication Cable SFTP CAT7 Lan Cable   Hangzhou Risun Cable specializes in producing Cables: UTP CAT5e, UTP CAT6, FTP CAT5e, FTP CAT6, SFTP CAT5e, SFTP CAT6, SF/UTP CAT5e, SF/UTP CAT6, CAT6A, CAT7 Telephone Cable, Alarm Cable, Coaxial Cable As a professional manufacturer we can provide the extra savings to our customers with the best quality to help our customers grow their business and market shares. 1. All of products we offer are top quality and competitive price; 2. If there is no special explanation, all of our Brand are RISUN or OEM; 3. Payment: We accept T/T and L/C; 4. Packing: 1) Packing Lengths: 305m/roll, or other lengths available according to client's request. 2) Inner packing: Wooden reel, plastic reel, and paper reel available. 3) Outer packing: Carton box, pull box 4) Other packing available according to client's request. 5. Any question, please contact us without hesitation. We'll reply as soon as we can. Construction Conductor 23AWG Bare Copper Insulation 1.35±0.05mm Cores/Pairs 8/4 1st shield Each pair Aluminum foil shielded 2 st Shield ≥40% Tinned Copper Sheath 7.9±0.3mm PVC /LSOH / PE

Mechanical Properties
Elongation	Min. 300%
Temperature Range	-20 up to +75° C
Tensile strength	Min. 1.68Kg/mm2

Electrical Properties (at 20°C)
Conductor Resistance	Max. 9.38 ohm/100m
Resistance Unbalance	Max. 2%
Insulation Resistance	150 ohm/KM
Mutual Capacitance	Max. 5600pF/100m
Cpacitance Unbalance	Max. 330pF/100m
Impendance	100+/-15 ohm
Spark Test	2000V
Velocity Propagation	67%

	Attenuation	RL	Next	PS Next
(MHz)	(db/100m)	(db)	(db)	(db/100m)
1MHz	2.0	20	65.3	63.5
4MHz	4.1	23	56.3	54.2
8MHz	5.8	24.5	52.4	50.5
10MHz	6.6	25	51.3	49.2
16MHz	8.2	25	49.3	47.4
20MHz	9.3	25	48.8	46.9
25MHz	10.4	24	45.3	43.4
31.25MHz	11.7	23	43.0	41.8
62.5MHz	17.0	21	39.2	37.2
100MHz	22.0	20	36.3	34.4
155MHz	28.1	19	35.5	33.6
200MHz	32.4	19	31.8	29.9
240MHz	36.0	18	30.6	28.7
300MHz	41.0	18	29.2	27
350MHz	44.9	17	28.0	25.6
